Magnetic drive, shaft seal-less design, primary raw materials, modular assembly. Ideal for corrosive chemical transfer in electroplating, PCB, and general industry.
.jpg)
.jpg)
.jpg)
Totally leak-proof design eliminates "running, exuding, dropping, leakage".
Enhanced corrosion resistance and structural strength for harsh chemicals.
Flange, union, nut, bolt connections to meet diverse installation needs.
Simple, robust structure for easy maintenance and part replacement.
Optimized hydraulics for lower energy consumption and stable flow.
| Model | Inlet (mm) | Outlet (mm) | Power (W) | 50Hz Max. (Head m / Flow L/min) | 60Hz Max. (Head m / Flow L/min) | ||
|---|---|---|---|---|---|---|---|
| Head | Flow | Head | Flow | ||||
| JM-2020 | 15 | 15 | 20 | 3 | 26 | 5 | 29 |
| JM-2045 | 15 | 15 | 45 | 3.8 | 31 | 5.1 | 39 |
| JM-2065 | 15 | 15 | 65 | 4.5 | 45 | 6.8 | 53 |
| JM-25120 | 25 | 25 | 120 | 5.6 | 60 | 8.1 | 66 |
| JM-25150 | 25 | 25 | 150 | 6.9 | 85 | 9.4 | 98 |
| JM-25260 | 25 | 25 | 260 | 8.8 | 120 | 13.7 | 120 |
* Other voltages and special materials available upon request.
Engineered for reliable, leak-free transfer of aggressive chemicals.
Seal-less magnetic drive eliminates mechanical seal wear.
FRPP/PVDF bodies withstand acids, alkalis, and solvents.
Easy maintenance, spare parts interchangeable.
Optimized hydraulics reduce power consumption.
Electroplating, PCB, chemical dosing, and more.
